Model	CHN-S-LCTR-DY610
Accuracy	±0.2%FS ±1 byte
Input signal	0~±20mV
Excitation voltage for load cell	DC 5-15V
Output signal *	DC 4-20mA, DC 0-5V, DC 0-10V, RS485 (Modbus-RTU), 4-20mA & RS485, 0-5V & RS485, 0-10V & RS485
Sampling rate	20 times/s, 80 times/s
Power supply	DC 12-30V
Power consumption	＜1W
Display	6 digit red LED, -99999~999999
