Model	CHN-LCMA-DYDW-005
Shipping weight	3kg
Capacity range *	X axis: 5N~5000N Y axis: 5N~5000N Z axis: 5N~5000N
Accuracy	0.5%F.S (linearity + hysteresis + repeatability)
Sensitivity	1.0mV/V
Creep	±0.5%F.S/30min
Zero output	±2%F.S
Temperature effect on zero	±0.05%F.S/10℃
Temperature effect on output	±0.05%F.S/10℃
Operating temperature	-20℃~+75℃
Input impedance	350Ω or 1000Ω
Output impedance	350Ω or 1000Ω
Insulation resistance	≥5000MΩ
Safety overload	150%F.S
Bridge voltage (excitation voltage)	DC 5-15V
Material	Alloy steel
Protection class	IP66
Cable length	4m (Φ6mm)
Wiring	EXC+: Red, EXC-: Black, SIG+: Green, SIG-: White
