Model	CHN-LCS-DYLY-106
Weight	0.06kg
Capacity range *	0kg~50kg
Accuracy	0.03%F.S (linearity + hysteresis + repeatability)
Sensitivity	2.0±0.05mV/V
Creep	±0.03%F.S/30min
Zero output	±1%F.S
Temperature effect on zero	±0.03%F.S/10℃
Temperature effect on output	±0.03%F.S/10℃
Operating temperature	-20℃~+80℃
Input impedance	350±20Ω
Output impedance	350±5Ω
Insulation resistance	≥5000MΩ
Safety overload	150%F.S
Bridge voltage (excitation voltage)	DC 5-15V, suggest DC 10V
Material	Alloy steel
Protection class	IP67
Cable length	2m
Wiring	EXC+: Red, EXC-: Black, SIG+: Green, SIG-: White
