Model	CHN-HTGTB-350
Capacity	3 kVA
Input Voltage	110V/ 120V/ 220V
Frequency	50Hz/ 60Hz
Output Voltage	50 kV
Current	60 mA
DC Output	70 kV
Phase	1 Phase
Weight (Transformer + Control Box)	48 kg
Cooling Method	Dry
Effeciency	90%
Impedance Voltage	<12%
Surface Temperature Raising	< 55°C
No Load Current	< 4%
Output Voltage Waveform	Sine Wave
Usage	AC DC Hipot Tester
Warranty	12 Months
Temperature Environment	0~40°C
Altitude	<2000m
Relative Humidity	<85%

NO.	Description	Quantity
1	Hipot Test Set (1 Control Box + 3 kVA Dry Transformer)	1
2	Power Supply Cable	1
3	Earth Cable	1
4	Connecting Line	1
5	Fuse	3
6	Rectifying Diode	1
7	User Manual	1
