Model	CHN-TL610D-050	CHN-TL610D-150	CHN-TL610D-300	CHN-TL618D-050	CHN-TL618D-150	CHN-TL618D-300
Output signal	Voltage output			Current output
Measuring range	±50°	±150°	±300°	±50°	±150°	±300°
Ratio factor	50mV °/S	16.66 mV °/S	8.333 mV °/S	-	-	-
Measuring axis	X, Y, Z (optional)
Bandwidth	>2000Hz
Resolution	0.1°/ s
Temperature drift	<±1°/ s
Nonlinear	0.1% of FS
Zero degree bias voltage	2.5V (±0.01V)
Starting time	<5s
Input voltage	9-36V
Output voltage	0-5V
Consumption current	6mA
Working temperature	-40℃-85℃
Storage temperature	-55℃-100℃
Capacitive load	1000 Pf
Shock	5g-10g
Impact	200g pk, 2ms, 1/2 sine
Connector	5 pins aviation socket, standard 1m cable
Working life	10 years
Output rate	5Hz/ 15Hz/ 25Hz/ 50Hz/ 100Hz can be set
MTBF	≥50000 hours/ times
Iusulation resistance	≥100M
Anti-vibration	10grms, 10-1000Hz
Protection grade	IP67
Certificate	CE, FCC, RoHS
Warranty	12 months
