Model	CHN-TL632D-050	CHN-TL632D-150	CHN-TL632D-300
Measuring range	±50°	±150°	±300°
Temperature drift	<±0.2°/ s	<±1°/ s	<±3°/ s
Measuring axis	X, Y, Z (optional)
Bandwidth	>2000Hz
Resolution	0.1°/ s
Nonlinear	0.1% of FS
Starting time	5 ms
Input voltage	9-36V
Current	6mA
Working temperature	-40℃-85℃
Storage temperature	-55℃-100℃
Capacitive load	1000 Pf
Shock	5g-10g
Impact	200g pk, 2ms, 1/2 sine
Connector	5 pins air-plug, matched with 1m cable
Working life	10 years
Output rate	5Hz/ 15Hz/ 25Hz/ 50Hz/ 100Hz/ 300Hz can be set
Output signal	RS232/ RS485/ RS422/ TTL/ SPI
MTBF	≥50000 hours/ times
Iusulation resistance	≥100M
Anti-vibration	10grms, 10-1000Hz
Protection grade	IP67
Certificate	CE, FCC, RoHS
Warranty	12 months
