Model	CHN-LW128B	CHN-HW228B
Full Range Precision	±0.3°	±0.1°
Temperature Drift	±0.02°/℃
Zero Drift	4mA
Measuring Range (Optional)	0 ~ 30°, 0 ~ 60°, 0 ~ 90°, 0 ~ 180°, 0 ~ 270°, 0 ~ 360°
Output Signal (Optional)	4-20mA, 2-20mA
Output Load	240Ω
Voltage Input	9 - 36V DC
Typical Voltage	12V
Sampling Frequency	1KHz
Linearity	0.5% - 0.15%
High Vibration Resistance	＞20000g
Frequency Response	100Hz
Angle Resolution	0.022°
Full Range Accuracy	±0.3°
Operating Temperature	-40 - +85℃
Storage Temperature	-55 - +100℃
Power-on Startup Time	0.2s
Response Time	0.01s
Average Operation Time	≥55000 Hour/Time
Cable	with 1.5m length shielded cable 3*0.3mm2
Power Reverse Protection	40mV
Signal Reverse Protection	40mV
Running Torque	＜10mN·m
Material	Shell: Aluminum Alloy Oxidation Back Cover: Stainless Steel Shaft: Stainless Steel
Protection Grade	IP66
Weight	1kg
