Model		CHN-PAR-400
Spectral Range	0-2500 μmol/m²s	400-700 nm
	0-2000 W/m²	350-1100 nm
Supply		5V DC, 12V-24V DC
Accuracy		±5% rdg
Range		0-2500 μmol/m²s, 0-2000 W/m²
Output		0-2000 mV	4-20 mA (2-wires)	RS485
Sensitivity	0-2500 μmol/m²s	800 μV/μmolm²*s	6.4 μA/μmolm²*s	/
	0-2000 W/m²	1000 μV/W/m²	8 μA/W/m²	/
Response Time		< 1s (99%)
Temperature Effect		< 0.05%/℃
Cosine Correction		< 10% (until 80°)
Non-linearity		< ±2%
Operating Temperature		-40 ℃— +80 ℃
Shell Material		Aluminum alloy
Storage Condition		10 ℃—60 ℃, 20%—90% RH
