Model		CHN-CJX2-F400
Rated Current	le max AC-3 (Ue≤440V)	400A
Rated Current	le max AC-1 (θ≤40°C)	500A
Coil Rated Voltage (Optional)		24V AC, 36V AC, 48V AC, 110V AC, 220V AC, 380V AC
Contact Form		3NO
Auxiliary Contact (Optional)		2NO, 2NC, 1NO+1NC, 2NO+2NC, 1NC+3NO, 4NO, 4NC
Frequency		50Hz/ 60Hz
Rated Insulated Voltage (Ui)		1000V
Rated Impulse Withstand Voltage (Uimp)		8kV
Rated Operational Voltage		1000V
Conventional Thermal Current (θ≤40°C)		500A
Operation Frequency	AC-1, AC-2, AC-3	600 times/h
Operation Frequency	AC-4	300A
Rated Power (AC-3)	220/240V	110kW
	380/400V	200kW
	415V	220kW
	440V	250kW
	500V	257kW
	660/690V	280kW
	1000V	185kW
Connection/ Wiring	Number of Lines	2
	Line Size	30x5mm²
	Cable with Splicing	2x150mm²
	Screw Diameter	φ10
Tightening Torque		35N.m
Standards-Compliant		IEC60947-4-1, GB14048.4, EN60947-4-1
Dimensions		206 x 213 x 219mm
Weight		19.5kg
