Basics	Model	CHN-SR-E16P
Basics	Weight	0.2 kg
Technical Parameters	AC supply voltage	24V
	DC supply voltage	24V
	Voltage tolerance	-15-+10℃
	Power consumption	AC: 2.5VA, DC: 2.0W
	Frequency	50-60Hz
	Resihual ripple	DC: 160％
	Voltage and current at reset circuit and feedback loop	UB=24V, DC: 25mA
	Safety contacts	(N/O): 3
	Auxliary contact	(N/C): 1
	Contact material	AgCuNi+0.2μAu
	Extermal contact fuse protection	EN 60947-5-1 (Ik=14kA)
	Blow-out fuse quick	10A
	Blow-out fuse slow	6A
	Safety cut-out	24V
	Characteristic	B/C
	Semiconductor output 24V	24V DC, 20mA
	Extermal power supply	24V DC
	Pollution degree	2
	Overage category	3/2
	Rated insulation	250V
	Rated impulse withstand	4kV
Environment	Ambient temperature	-10℃~+55℃
Environment	Storage tempetature	-40℃~+85℃
