Model	CHN-TS-AD16102E2
Rated Current	5A
Rated Voltage	3~250V AC/DC
Position	2 Position, on/off
Pin	6 Pin
LED Life Time	≤50,000 Times
Insulation Resistance	≥100 MΩ
Action Force	2.0±0.2N
Action Method	Automatic Lock
Protection Level	IP67
Operating Temperature	-25℃~55℃
Contact Resistance	25mΩ
Nut Tightening Force	16N
Electrical Life Time	≥50,000 Times
Switch Stroke	1.2mm
Warranty	12 Months
Weight	17.8g
