100 MHz Digital Oscilloscope, 2/4 Channels, 4 GSa/s

Close
Shopping Categories
Search

100 MHz Digital Oscilloscope, 2/4 Channels, 4 GSa/s


$1599.85
Rigol 100 MHz digital oscilloscope from ATO uses UltraVision innovative technology which combines 140 Mpts high memory depth
SKU: CHN-SCOPE-100M
Free Shipping Worldwide
Delivery date: 6-12 days

100 MHz Digital Oscilloscope Features

  • 100 MHz maximum bandwidth, you can view up to 100 MHz digital/analog signals clearly.
  • 2 or 4 analog channels for your selection.
  • Digital storage with 140 Mpoints memory depth.
  • 4 GSa/s maximum real-time sample rate.
  • Lower noise floor, the minimum vertical sensitivity is 1mV/div.
  • Up to 110,000 wfms/s maximum waveform capture rate.
  • 9 inch WVGA (800×480) and 256 level intensity grading display.

Models and Key Specifications

Brand NameRIGOL
ModelDS4012DS4014
MSO4012MSO4014
Number of Analog Channels24
Number of Digital Channels (For MSO Series)16
Bandwidth100 MHz
Max. Real-time Sample RateAnalog channel up to 4 GSa/s
Digital channel up to 1 GSa/s (MSO Series)
Max. Memory DepthAnalog channel up to 140 Mpts
Digital channel up to 28 Mpts (MSO Series)
Max. Waveform Capture Rateup to 110,000 wfms/s
Real-time, Hardware Waveform Recording, Playback, and Analysis FunctionsAnalog channel up to 200,000 frames
Digital channel up to 64,000 frames (MSO Series)
Multi-level Intensity Grading Displayup to 256 levels
Standard probes2 or 4 sets RP3500A 500 MHz BW Passive Probe
1 sets RPL2316 LA Probe (MSO series only)
DimensionWidth x Height x Depth = 440 mm x 218 mm x 130 mm
Weight7 Kg (Package Included)
Packing Included1 x Digital Oscilloscope; 2 (4) x Probes; 1 x USB Cable; 1 x Power Cord; 1 x Quick Guide

DS/MSO4000 Series Rigol Digital Oscilloscope Specs PDF

Digital Oscilloscope Detail
digital oscilloscope detailsTips: Digital Oscilloscope vs. Analog Oscilloscope
The oscilloscope is divided into digital oscilloscope and analog oscilloscope.

The analog oscilloscope uses analog circuit (the oscillograph tube, which is based on the electron gun). The electron gun launches electrons to the screen, and the emitted electrons are focused on forming the electron beam and hitting the screen. The inner surface of the screen is coated with a fluorescent substance, so that the dots in the electron beam will emit light.

Digital oscilloscope is a high performance oscilloscope produced by a series of technologies such as data acquisition, A/D conversion and software programming. Digital oscilloscope generally supports multi-level menus, which can provide users with multiple choice and analysis functions. At the same time, it can also provide storage and realize the preservation and processing of waveforms.
