Model	ATOWG-12S2815
Input	Rated voltage	12V
	Voltage range	10-18V
	Efficiency	95% @ 12V input
Output	Voltage	28V
	Max. rated current	15A
	Max. rated power	420W
	Voltage regulation	±1%
	Load regulation	2%
	No load loss	70mA
	Ripple & noise	200mV
Environment	Working temperature	-35 ~ +80℃
	Working humidity	10% ~ 90%RH
	Storage temperature	-40 ~ +85℃
Function	Short circuit protection	NO
	Over current protection	YES
	Waterproof	IP68
	Over temperature protection	YES
	Over voltage protection	YES
Mechanical	Weight	500g
	Size	1008039mm

Code	Model	Price	Input Voltage	Output Voltage	Output Current	Output Power	Efficiency	Size	Download
1	ATOWG-12S2805	$69.29	12V DC	28V DC	5 Amps	140 Watts	94%	747432mm
2	ATOWG-12S2808	$77.99	12V DC	28V DC	8 Amps	224 Watts	94%	747432mm
3	ATOWG-12S2810	$86.69	12V DC	28V DC	10 Amps	280 Watts	94%	747432mm
4	ATOWG-12S2815	$112.39	12V DC	28V DC	15 Amps	420 Watts	95%	1008039mm
5	ATOWG-12S2820	$159.59	12V DC	28V DC	20 Amps	560 Watts	96%	15012763mm
6	ATOWG-12S2830	$199.89	12V DC	28V DC	30 Amps	840 Watts	96%	15012763mm
7	ATOWG-12S2840	$269.19	12V DC	28V DC	40 Amps	1120 Watts	95%	22012763mm
